ESYLUX EP10431616 Pushbutton IP20 White
EAN:
Part number:
Item no:
Technical specifications
- KNX bus system: No.
- Bus system KNX radio: No.
- Bus system wireless bus: No.
- Bus system LON: No.
- Bus system Powernet: No.
- Other bus systems: Other
- Wireless bidirectional: No
- Mounting type: Flush-mounted
- With theft/dismantling protection: No.
- With bus connection: Yes
- Number of operating points: 4
- Number of keys: 4
- With LED indicator: No.
- With marking field: Yes
- With display: No.
- Material: Plastic
- Material quality: Thermoplastic
- Surface protection: Untreated
- Design of surface: Matt
- Colour: white
- RAL number (similar): 9003
- Transparent: No.
- With room thermostat: No.
- With infrared sensor: No.
- Protection class (IP) IP20
- Min Depth of the device socket 8 mm
- Product type
Pushbutton
- Mounting type
Flush mount
- Factory colour
White
IP20
- Content
1 pc(s)
- Material (details)
Plastic
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3159159 ESYLUX EP10431616 Pushbutton IP20 White
Description
4-way button as a certified DALI-2 input device. Individual function assignment via Application Controller (DALI-2 control unit). Function assignments of the keys can be individually identified. Power supply via DALI bus. Compatible with 55 mm frames from popular manufacturers.
