Eurolite 50530143 LED strip EEC: G (A - G) open cable ends 24 V 5 m RGB 5 m
EAN:
Part number:
Item no:
Product type
LED strip
Connectors (LED strips)
open cable ends
LED strip features
Self-adhesive
Colour
RGB
Total luminous flux
4750 lm
Highlights & Details
Eurolite LED strip 300 5m 5050 RGB/WW/CW 24V
- Product size (length)= 5 m
- Total luminous flux= 4750 lm
- RGB
Technical specifications
- Product type
LED strip
- Connectors (LED strips)
open cable ends
- LED strip features
Self-adhesive
- Factory colour
White
- Colour
RGB
- Min. colour temperature
3000 K
- Total luminous flux
4750 lm
- Use
Inside
- Luminous flux (Φ)
4750 lm
- Operating voltage
24 V
- Dim
(L x W x H) 5 m x 1.2 cm x 2 mm
- Power consumption
115 W
- Power consumption per unit
23 W
- LEDs
300
- LED number per unit
300
- Width
1.2 cm
- Height
2 mm
- Length
5 m
- Unit length
10 cm
IP20
G (A - G)
- Energy consumption
115 kWh/1000h
- No. of bulbs
300
- Weight
150 g
16 lm
- Protection class
III
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2890506 Eurolite 50530143 LED strip EEC: G (A - G) open cable ends 24 V 5 m RGB 5 m
Description
Flexible LED strips, RGB, warm white and cool white Flexible LED strips for the interior decoration lighting
High-quality materials and a solid design guarantee a long life and excellent color reproduction
Variable divisible in segments
This text is machine translated.
High-quality materials and a solid design guarantee a long life and excellent color reproduction
Variable divisible in segments
This text is machine translated.
Features
- Self-adhesive back side
- Supplied on plastic coil
- 300 powerful LEDs SMD 5050 4in1 QCL RGB/WW (homogeneous color mixing)
- Can be controlled via System Controller
- For applications such as: Trade fairs and shops
- Voltage supply: 24 V DC / 4.8 A
- Total connected wattage 115 W
- Protection class: IP20
- Protection class SK III.
- Luminous flux (lumen) per meter: 950 lm/m
- Power connection: Fixed connection cable with open cable ends
- Cable length approx. 0.15 m
- 300 x SMD 5050 4in1 QCL RGB/WW (homogeneous color mixing)
- Control: System controller
- Mounting/mounting: Self-adhesive
- Bulbs/Meter: 60 piece Power/Meter: 23 W
- Lamps/hose 300 pieces
- Lamp distance 16 mm
- Cutting marker 10 cm
- Housing color: White
Scope of delivery
- 1 bulbs
- 1 x Operating manual
