Eurolite AKKU B-40 AIR Laser light effect
EAN:
Part number:
Item no:
Technical specifications
- Power supply (details)
Integrated rechargeable battery; 100 - 240 V
- Product type
Laser light effect
- Laser category
2M
- Colour
RGBW
- Dim
(W x H) 32 cm x 39 cm
- Weight
6.90 kg
- Effect
Beam effect
- Light features
Battery-powered
- Laser power (green)
40 mW
- Laser power (red)
100 mW
- Width
32 cm
- Height
39 cm
IP20
- Case colour
Black (matt)
- Material
Metal (painted)
- Protection class
I
- Operating voltage
100-240 V/AC, 50/60 Hz
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3642524 Eurolite AKKU B-40 AIR Laser light effect
Description
Battery-LED-radiation effect with RGBW colors, RG-laser, AirW-radio unit (2.4 GHz) and remote control. Integrated AirW radio transceiver for wireless Master / slave operation. Adaptive frequency hopping for interference-free signal transmission in the 2.4 GHz band. 2 laser diodes project hundreds of red and green laser beams. Wireless, flexible and versatile. Battery life up to 11h depending on the program used. Built-in automatic charging. 5 powerful LEDs 8 W SMD 9095 4in1 QCL RGBW. 3 segments can be controlled individually. Electronic dimmer; adjustable color selection; manual program selection; adjustable energy-saving mode; adjustable speed of run; Rotation speed adjustable, rotation direction adjustable. Beam effect; Laser; Stroboscope-effect. Class 2M laser, no inspection or order is required by a laser safety officer. 7 integrated show programs. Highly efficient air flow front to rear. The cooling of the device takes place via the fan noiselessly in the base; fan in the head. Can be controlled via stand-alone; DMX; AirW; music control via microphone; Master/slave function; Radio Remote Control; QuickDMX via USB (optional); W-DMX by Wireless Solution via USB (optional); CRMX by Lumen Radio via USB (optional). Flicker-free. DMX failure mode (blackout; hold; auto; full on). With Omega bracket. Single-color 4-digit 7-segment LED display. Battery level indicator Power input and power output for simple connection of up to 8 devices. For application areas like: Clubs/dance schools; wedding/gala/events; mobile DJ's / solo entertainer; party cellar; restaurants, bars and hotels; advertising/shop window. Very quiet operation. Possible application: Standing; flying. 3 buttons of the remote control for storing your own settings; light effect. AirW: Range of up to 70m at visibility; remote control. Range of up to 30m at sight range
This text is machine translated.
This text is machine translated.
Features
- Power supply: 100-240 V AC, 50/60 Hz; Protection type: IP20; Protection class: SK I; Power connection: Power supply via cold device (M) Installation version Power connection cable with safety plug (supplied); built-in battery/rechargeable battery; Design cable: 5 x 20 mm² H05VV-F; Current output: 2 x cold devices (W) Installation version Bypass; Device fuse: 3 x 1.0 mm, T 1 A fuse can be replaced; Battery type: 1 x Lithium-Ion 18.5 V, 13000 mAh, 240.5 Wh; battery: operating time up to 11h depending on the program used; charging time 7h; LED type: 1 x 8 W SMD 9095 4in1 QCL RGBW; flash rate: 5 - 20 Hz; laser class: 2M; laser color: R/G; laser module: red (R) 100 mW 650nm; green (G) 40 mW 532nm; DMX channels: 3; 10; 22; DMX input: 1 x 3-pin XLR (M) mounting version; DMX output: 1 x 3-pin XLR (W) mounting version bypass; cooling: 1 x fans quiet in the base, air flow front to rear; 1 x fans in the head; control: stand-alone; DMX; AirW; music control via microphone; Master/slave function, wireless remote control; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by Lumen Radio via USB (optional); Projection: flicker-free; DMX failure mode: blackout; hold; auto; Full on; Housing color: matte black; Recording system: Omega brackets; Display type: 4 6.90-digit 7-segment LED single color; Display: charging status LED: charging status LED: charging status indicator; USB-connection: 39 x type A; Material: metal, painted; Dimensions: length: 32 cm; width: 1 cm; Weight: 1 kg; Noise classification: Class 26 (very light noise, suitable for noise sensitive environments); Lighting effect; Range: AirW: up to 70m at visibility; carrier frequency: 2.4 GHz; Omega bracket; material thickness: 3 mm; remote control; Battery:1 x 12 V 23AE Integrated alkali-manganese; Range: Up to 30m in visibility; Carrier frequency: 433.92 MHz
Scope of delivery
- 1 x lighting effects
- 1 x Power cable/power cable
- 1 x Omega clip
- 1x user manual
- 1x remote control
- 4 x Screws
- 4 x washers
- 1 x declaration of conformity
- 1 x battery
Hints
CAUTION! High-voltage lasers must be operated by authorised staff holding the appropriate qualifications. The OHS officer needs to ensure the operational safety of the used laser equipment and its full compliance with all relevent Health & Safety regulations.
