Eurolite AKKU Bar-6 Entry QCL RGBW Leiste LED cordless spolight
EAN:
Part number:
Item no:
Highlights & Details
Eurolite BATTERY bar-6 entry QCL RGBW pin
- Wireless, flexible and versatileEquipped with 6 x 8 W QCL LEDs in red, green, blue and whiteOperation via mains connection or built-in lithium-ion battery with up to 15 hours operating time (depending on the program used)
Technical specifications
- Power supply 100-240 V AC, 50/60 HzProtection class: IP20Protection class SK IPower connection: Power feed cold devices (M) Built-in version Power connection cable with earthing contact plug (included)Power output: Cold-devices (W) built-in versionFuse: T 0.5 A fuse replaceableBattery type: 1 x Lithium-Ion 22.2 V, 2200 mAh, 48.84 WhType of lamp: LED lampLED: 6 x high-power 8 W 4in1 QCL RGBW (homogeneous color mixing)Flash rate 0 - 20 HzDMX channels: 3; 4; 4; 6; 8DMX input: 3-pin XLR (M) mounted versionDMX output: 3-pin XLR (W) mounted versionCooling: Passive convection coolingControl: Stand-alone; IR remote control; DMX; QuickDMX via USB (optional); Master/Slave function; Music control via microphoneBeam angle: 18°Beam angle (1/2 peak): 18°Angle of radiation (1/10 peak): 35°Housing colour black.Display type: 4-digit 7-segment LED displayDimensions: Length: 54.5 cmDepth: 13.8 cmHeight: 15.7 cmWeight: 2.76 kgRemote controlBattery: 1 x button cell 3.0 V CR2025 lithium manganese (included)Legal SpecificationsSpecial product: Not intended for domestic lightingIntended use: Lighting for show effects
- Product type
LED cordless spolight
n.rel.
- Weight
2.76 kg
- Height
15.7 cm
- Factory colour
Black
- Depth
13.8 cm
- No. of bulbs
6
IP20
- Radiation angle
18°
- Operating voltage
100 V
240 V
- Protection class
I
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2533023 Eurolite AKKU Bar-6 Entry QCL RGBW Leiste LED cordless spolight
Description
Battery light effect strip with RGBW LEDs and IR remote control
This text is machine translated.
This text is machine translated.
Features
- Charging time 3 hourspower-saving modeAuto, sound, master/slave and DMX modeMusic control via in-built microphone with adjustable microphone sensitivityCompatible with QuickDMX - the radio DMX system from EurolitePhantom-powered USB socket for QuickDMX receiver (accessories)Integrated show programs in auto and sound modeDirect color selection for 19 colorsContinuous RGBW color mixing, color change, color blending, dimmer and strobe effect with variable speed, music controlAddressing and settings via control unit with four-digit LED displayConvenient remote control via the supplied IR remote control EUROLITE IR-7Swiveling mounting bracketIEC mains connections for simple series connection of up to 8 devicesSwitched-mode power supply technology for mains voltage between 100 and 240 voltsBattery type: 1 x Lithium-Ion 22.2 V, 2200 mAh, 48.84 Wh
Scope of delivery
- Eurolite BATTERY bar-6 entry QCL RGBW pin
