Eurolite KLS Scan Pro Next FX DMX LED effect light
EAN:
Part number:
Item no:
Technical specifications
- 5 x 7 W high-power 4in1 QCL RGB/WW (homogeneous color mixing)
- Beam angle: 15°
- Beam angle (1/2 peak) 15°
- Beam angle (1/10 peak) 30°
- Lighting effect LED:2 x 3 W R/G/B
- Moving light LED:1 x 37.5 W cold white (CW)
- Bar LED:4 x 1 W high-power ultraviolet (UV)
- Button cell 3.0 V CR2025 Lithium-Manganese installed (included)
- DMX channels 3; 7; 13; 14; 15; 18; 19; 30; 32; 39
- DMX input 1 x 3-pin XLR (M) installation version
- DMX output 1 x 3-pin XLR (W) built-in version
- Spot red (R) 1m: 2300 lx, 3M: 235 lx, 6m: 58 lx
- Spot green (G) 1m: 4187 lx, 3M: 422 lx, 6m: 107 lx
- Spot blue (B) 1m: 760 lx, 3M: 78 lx, 6m: 20 lx
- Spot Warm White (WW) 1m: 3290 lx, 3M: 325 lx, 6m: 85 lx
- Spot every 1m: 10283 lx, 3M: 1010 lx, 6m: 259 lx
- Ultraviolet (UV) 1m: 30 lx, 3M: 4 lx, 6m: 1 lx
- Protection class: IP20
- Protection class: I
- Product type
DMX LED effect light
- Factory colour
Black
n.rel.
- Dim
(L x W x H) 1120 x 100 x 420 mm
- Weight
15.10 kg
- Width
100 mm
- Height
420 mm
- Length
1120 mm
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2898782 Eurolite KLS Scan Pro Next FX DMX LED effect light
Description
Compact strips with derby, spots, scanners, UV-effect, QuickDMX socket and bag.
This text is machine translated.
This text is machine translated.
Features
- Herzchen-Gobo for romantic occasions
- Power input and power output for simple connection of up to 8 devices
- Positioning within PAN and TILT
- Colour wheel with 7 dichroic colors and open
- Gobo wheel with static gobos, 7 gobos and open
- 20 integrated show programs
- In 3; 7; 13; 14; 15; 18; 19; 30; 32; 39 CH DMX mode can be operated
- The device is cooled by a fan
- Can be controlled via stand-alone; music control via microphone; master/slave function; IR remote control; DMX; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by Lumen Radio via USB (optional); wireless foot switch (optional); quick selection potentiometer for brightness
- Flicker-free
- Speaker mount adapter
- OLED Display
- For applications such as: Wedding/gala/events; mobile DJ's/solo entertainer; distributor
- Colour wheel; gobo wheel with static gobos
- Already pre-programmed at Light Captain; EASY SHOW 2; EASY SHOW 3
- With mounting bracket
- Program selection; Electronic dimmer; Colour mixing variable
- Stroboscope-effect; Radiation-effect
- The item is pre-assembled at delivery
- Headlight 5 powerful LEDs 7 W high-power 4in1 QCL RGB/WW (homogeneous color mixing)
- 4 spots can be controlled individually
- With an angle of radiation of 15°
- Light-effect 2 powerful LEDs 3 W R/G/B
- Moving light1 powerful LED 37.5 W cold white (CW)
- Leiste4 powerful LEDs 1 W high-power ultraviolet (UV)
- LEDs can be controlled individually
Scope of delivery
- KLS Scan Pro Next FX
- Remote control
- Bag
- Mounting bracket
- Knurl head screws
- Power cable;
- User manual
