Eurolite MD-2010 Mirror ball motor 19 cm
EAN:
Part number:
Item no:
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 31.92
3
4% = € 1.25
€ 30.67
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 31.92 / piece)
€ 31.92
plus VAT.
14-day return policy included
Highlights & Details
Eurolite MD-2010 safety rotary motor
- Mirror ball motor for balls up to 50 cm
Technical specifications
- Power supply: 230 V AC, 50 Hz
- Total connected wattage 3.5 W
- Max. Load WLL (4-fold): 30 kg
- Max. Load BGV C1 (8-fold): 15 kg
- Max. Load BGV C1 (10-fold): 12 kg
- Max. Load BGV C1 (12x): 10kg
- Max. Mirror ball diameter 50 cm (EUROLITE)
- Rotation speed: Approx. 1 rpm
- Base plate diameter 190 mm
- Height: 130 mm
- Weight 1 kg.
- Product type
Mirror ball motor
n.rel.
- Rotational speed
1 U/min
- (Ø)
19 cm
- Height
13 cm
- Weight
1 kg
- Operating voltage
230 V
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 592049 Eurolite MD-2010 Mirror ball motor 19 cm
Description
Mirror ball motor for balls up to 50 cm · For driving mirror balls up to a max. total weight of 10 kg · This corresponds to a diameter of 50 cm for EUROLITE mirror balls · The maximum load capacity always refers to the actual weight of the mirror ball including mirror ball chain, safety chain and fixing material · 2 chains and 4 quick connectors must be ordered separately · 1 revolution per minute · Supplied with open cable ends · For professional use, e.g. in discotheques and meeting places, the regulations of the BGV C1 (formerly VBG 70) must be observed · The engine must always be installed with a second independant suspension · The device must be checked by an expert before it is put into operation for the first time
This text is machine translated.
This text is machine translated.
Hints
Please order 2 chains and 4 quick connectors by special order.
