Eurolite MD-2030 Mirror ball motor DMX-controlled
EAN:
Part number:
Item no:
Technical specifications
- Power supply: 230 V AC, 50 Hz ~
- Total connected load 13 W.
- Max. Load WLL (4-fold): 30 kg
- Max. Load BGV C1 (8-fold): 15 kg
- Max. Load BGV C1 (10-fold): 12 kg
- Max. Load BGV C1 (12x): 10kg
- Max. Mirror ball diameter 50 cm (EUROLITE)
- Rotation speed: Up to 5 rpm.
- Dimensions (LxWxH) 230 x 222 x 140 mm
- Weight: 3 kg.
- Shipping weight: 2,450 kg
- Product type
Mirror ball motor
- Features
DMX-controlled
n.rel.
- Rotational speed
5 U/min
- Height
15 cm
- Weight
3 kg
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1375779 Eurolite MD-2030 Mirror ball motor DMX-controlled
Description
DMX-controlled globe mirror motor.
This text is machine translated.
This text is machine translated.
Features
- For driving mirror balls up to a max. total weight of 10 kg
- This corresponds to a diameter of 50 cm for EUROLITE mirror balls
- The maximum load capacity always refers to the actual weight of the mirror ball including mirror ball chain, safety chain and fixing material
- Can be operated in standalone mode or DMX interface
- DMX512 control possible via any standard DMX controller (occupies 1 channel)
- Functions: Rotation direction, rotation speed, master/slave
- Adjustable via DIP-switch
- 2 chains and 4 quick connectors must be ordered separately
- Ready to connect via mains cable with earthing contact plug
- For professional use, e.g. in discotheques and meeting places, the regulations of the BGV C1 (formerly VBG 70) must be observed
- The engine must always be installed with a second independant suspension
- Before first use, the device must be checked by a Sacshenter
