Eurolite PLL-168 LED flasher
EAN:
Part number:
Item no:
Technical specifications
- LED:84 x 0.5 W SMD 2835 cold-white (CW), 84 x 0.5 W SMD 2835 warm-white (WW)
- Adjustable color temperature 2800K - 6500K
- Flash rate 0 - 20 Hz
- DMX channels 2; 4; 6
- DMX input 3-pin XLR (M), built in version
- DMX output 3-pin XLR (W) built-in version
- Beam angle: 120°
- Beam angle (1/2 peak) 120°
- Colour rendering index (CRI): 92 Ra
- Protection class: IP20
- Protection class: I
- Product type
LED flasher
- Colour
Cool white
Warm white
- Dim
(L x W x H) 117 x 357 x 220 mm
- Weight
3600 g
n.rel.
- LEDs
168
- Bulb type
LED (monochrome)
- Width
357 mm
- Height
220 mm
- Length
117 mm
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2898775 Eurolite PLL-168 LED flasher
Description
Battery-operated surface light with 168 dual-white LEDs, QuickDMX-socket and wing limiter.
This text is machine translated.
This text is machine translated.
Features
- Wireless and versatile
- Electronic dimmer
- Variable PWM frequency (pulse-width modulation)
- power-saving mode
- Perfect glare and transport protection through 4 door panels
- Flat, robust metal housing
- Power input and power output for simple connection of up to 8 devices
- Battery life up to 8h depending on the program used
- 84 powerful LEDs 0.5 W SMD 2835 cold-white (CW)
- Variable color temperature 2800 K - 6500 K
- Integrated show programs
- Direct color selection for 38 colors
- Can be used in 2; 4; 6 CH DMX mode
- The device is cooled by passive convection cooling
- Can be controlled via stand alone; music control via microphone; master/slave function; DMX; speed selection potentiometer for brightness and color temperature; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by Lumen Radio via USB (optional)
- Flicker-free
- With an angle of radiation of 120°
- Very high color rendering index (CRI)
- With mounting bracket
- 4 digit 7-segment LED display
- 84 powerful LEDs 0.5 W SMD 2835 warm-white (WW)
- Pre-programmed by Light Captain
- Can be used for applications such as video and photography; stage
Scope of delivery
- Headlamps
- Power cable;
- User manual
