Eurolite STP-14 Sunbar LED bar No. of LEDs (details): 314
EAN:
Part number:
Item no:
Highlights & Details
Eurolite LED STP-14 Sunbar
- 180 powerful LEDs SMD 3535 cold-white (CW) segments can be controlled individually
- 120 powerful LEDs SMD 5050 3-in-1 TCL RGB (homogeneous color mixing) segments can be controlled individually
- 14 powerful LEDs 3 W high-power warm-white (WW) segments can be controlled individually
Technical specifications
- Operating voltage
100 - 240 V
- Product type
LED bar
95 W
- LEDs
314
- Colour
RGB
Cool white
Warm white
- Dim
(L x W x H) 1000 x 90 x 85 mm
- Weight
3.88 kg
n.rel.
- DMX control
Yes
- Width
90 mm
- Height
85 mm
- Length
1000 mm
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3131246 Eurolite STP-14 Sunbar LED bar No. of LEDs (details): 314
Description
LED Sunbar with 3 effects: Warm-white beam effects, strobe and ambient light
3 impressive effects in one device: Beam effect, strobe and ambience light
This effect is particularly well appreciated in foggy conditions.
Colour change adjustable; dimmer electronic; color mixing variable; running light adjustable
Stroboscope-effect
Integrated show programs
Direct color selection for 10 colors
The device is cooled by passive convection cooling
Can be controlled via DMX; master/slave function; stand-alone; music control
Flicker-free
With an angle of radiation of 6.5°
With mounting bracket
Already pre-programmed at Light´J; LED PC-Control 512; Light Captain
Power input and power output for simple connection of up to 8 devices
Noiseless operation
CREE LED installed
4 digit 7-segment LED display
For application areas like: Clubs/dance schools; installation; stage; restaurants, bars and hotels
Possible application: Flying; wall mounting
This text is machine translated.
3 impressive effects in one device: Beam effect, strobe and ambience light
This effect is particularly well appreciated in foggy conditions.
Colour change adjustable; dimmer electronic; color mixing variable; running light adjustable
Stroboscope-effect
Integrated show programs
Direct color selection for 10 colors
The device is cooled by passive convection cooling
Can be controlled via DMX; master/slave function; stand-alone; music control
Flicker-free
With an angle of radiation of 6.5°
With mounting bracket
Already pre-programmed at Light´J; LED PC-Control 512; Light Captain
Power input and power output for simple connection of up to 8 devices
Noiseless operation
CREE LED installed
4 digit 7-segment LED display
For application areas like: Clubs/dance schools; installation; stage; restaurants, bars and hotels
Possible application: Flying; wall mounting
This text is machine translated.
Features
- Power supply: 100 - -240 V AC 50/ 60 Hz
- Total connected wattage 95 W
- Power connection: Power feed via P-Con (blue), installation version power connection cable with safety plug included
- Display type: 4 digit 7-segment LED display
- Protection class SK I
- Cooling: Passive convection cooling
- Housing colour black.
- Protection class: IP20
- Support system: 2x mounting bracket
- DMX control
- Cable configuration 3 x 1.5 mm² H05VV-F
- LED lamp type
- 180 x SMD 3535 cold-white (CW)
- DMX channels: 2
- DMX input 1 x 3-pin XLR (M) installation version
- Master/slave function
- Pre-programmed at: Light´J
- Light captain: Light captain
- Beam angle: 6.5°
- Angle of radiation (1/2 peak) Spot 6.5°
- Special product: Not intended for room lighting in homes
- Intended use: Lighting for show effects
- Fuse: T 3.15 A fuse fixed (e.g. on board)
- DMX output 1 x 3-pin XLR (W) built-in version
- Diameter of mounting holes 4 x Ø8mm
- Stand-alone
- Metal
- LED PC Control 512
- 120 x SMD 5050 3in1 TCL RGB (homogeneous color mixing)
- 14 x 3 W high-power warm-white (WW)
- LED manufacturer: CREE
- Music synchronisation
Scope of delivery
- Lighting effect
- Network cable/power cable
- User manual
