Eurolite Theatre spotlight Theatre COB 200 Warm white 200 W
EAN:
Part number:
Item no:
Technical specifications
- Product type
Theatre spotlight
200 W
- Dim
(W x H x D) 25.95 x 37.65 x 20.00 cm
- Weight
4.11 kg
n.rel.
- Colour
Warm white
- Width
25.95 cm
- Height
37.65 cm
- Depth
20.00 cm
IP20
- Case colour
Black
- Radiation angle
17°
- Protection class
I
- Operating voltage
100-240 V/AC, 50/60 Hz
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3642581 Eurolite Theatre spotlight Theatre COB 200 Warm white 200 W
Description
LED theater headlights with warm white (WW) 200-W COB (Chip-on-board) LED. 1 powerful LED 200 W COB (chip-on-board) warm white (WW). Electronic dimmer. Stroboscope-effect Integrated show programs. The device is cooled by a fan. Can be controlled via stand-alone; IR remote control; DMX; Master/slave function; music control via microphone QuickDMX via USB (optional); W-DMX by Wireless Solution via USB (optional); CRMX by Lumen Radio via USB (optional). Already pre-programmed at Light´J; Light Captain; Colorchief. Flicker-free. With an angle of radiation of 17°. Very high color rendering index (CRI). With double bow. LCD display Power input and power output for simple connection of up to 8 devices. For application areas like: Stage; wedding/gala/events; trade fair and shop building; theater; distributor; Video and photography. Very quiet operation. Possible application: Standing; flying; on a tripod
This text is machine translated.
This text is machine translated.
Features
- Power supply: 100-240 V AC, 50/60 Hz; total connected wattage: 150 W; protection class: IP20; protection class: SK I; Power supply: power feed via P-Con (blue), built-in version power supply cable with shock-proof plug (included); current output: P-Con (gray), built-in version; lamp type: LED lamp; LED type: 20 4 x 1 3 W COB (chip-on-board) warm-white (WW); flash rate: 0 2 3 - 1 Hz; DMX channels: 200; DMX input: built-alone XLR control (M) Master/slave function; music control via microphone; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by Lumen Radio via USB (optional); pre-programmed by: Light´J; Light Captain; Colorchiefs; Projection: flicker-free; Radiation angle: 17 4.11°; Angle of radiation (1/2 peak): 17°; Radiation angle (1/10 peak): 35°; Colour temperature: 3200K; Colour reproduction index (CRI): 98 Ra; Housing color: black; Recording system: Double bracket; Display type: LCD display; Dimensions: width: 25.95 cm; Depth: 1 cm; Weight: 37.65 kg; Noise classification: Class 20.00 (very light noise, suitable for noise sensitive environments); Photobiology security: Risk Group 0; Remote control; Battery: 1 x button cell 3.0 V CR2025 Lithium manganese installed; Legal specifications; Special product: Not intended for use in domestic lighting; intended use: lighting for show effects
Scope of delivery
- 1 x device
- 1x user manual
- 1 x Power cable/power cable
- 1x remote control
- 1 x battery
