EVN 678710 678710 Recessed floor light GU10 High-voltage halogen lamp Stainless steel
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Swiveling sunken ground light, IP67
Technical specifications
- Product type
Recessed floor light
- Operating voltage
230 V AC
- Outside Ø
135 mm
- Bulb type
High-voltage halogen lamp
GU10
- Rating per bulb
35 W
- Recess diameter
125 mm
- Recess depth
160 mm
- Protection screen
Textured
- Light features
Hardwearing
- Swivel range (max.)
15°
- Protection class
I
IP67
- Factory colour
Stainless steel
- Material
Aluminium
- Feed length
100 cm
n.rel.
- Light bulb included
No
- Height
145 mm
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 2483523 EVN 678710 678710 Recessed floor light GU10 High-voltage halogen lamp Stainless steel
User & Safety Instructions
User & Safety Instructions 2483523 EVN 678710 678710 Recessed floor light GU10 High-voltage halogen lamp Stainless steel
Description
The cover plate made of V2A stainless steel sits on an aluminum lamp housing, which is covered with polyester to protect against corrosion. The lead through a cable gland has a length of 100cm. The GU10 mains voltage socket allows different bulbs up to 35W to be used in the lamp. The maximum overtravel speed is 20km/h. The light bulb holder is mounted in a rotating position in the lamp and has a swivel angle of 15°.
This text is machine translated.
This text is machine translated.
Hints
Please order lamp separately.
