EVN DALPD23400 LED dimmer 400 W 45 mm 46 mm
EAN:
Part number:
Item no:
Product type
LED dimmer
Type
DALPD23400
Power (max) P(TOT)
400 W
Dim
(L x W) 45 mm x 46 mm
Width
46 mm
Datasheet (PDF)
Technical specifications
- Type
DALPD23400
- Product type
LED dimmer
- Power (max) P(TOT)
400 W
- Dim
(L x W) 45 mm x 46 mm
- Width
46 mm
- Length
45 mm
n.rel.
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2483658 EVN DALPD23400 LED dimmer 400 W 45 mm 46 mm
User & Safety Instructions
User & Safety Instructions 2483658 EVN DALPD23400 LED dimmer 400 W 45 mm 46 mm
Description
The DALI dimmer receiver can be controlled both via the DALI bus and via a button (8V to 230V/AC/DC). Thus, different consumers can be dimmed and switched on/off. The maximum power is 200W for LED consumers as well as low-voltage halogen lamps and 400W for HV halogen lamps. Protocol: dt6, DALI2.
