Exsys Exsys EX-1116HMVS - Hub - 16 x USB 3.1 Gen 1 USB hub Black
EAN:
Part number:
Item no:
Datasheet (PDF)
EXSYS EX-1116HMVS port hub 5000 Mbit/s
Highlights & Details
- Hub interfaces: USB 3.2 Gen 1 (3.1 Gen 1) Type-A
- Number of connections: 16
- 5000 Mbit/s
- Metal
Technical specifications
- Data transfer rate 5000 Mbit/s.
- Supports Windows operating systems: Windows 2000 8, Windows 2000 Professional, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise x64, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
- Product type
USB hub
- Factory colour
Black
- Weight
1 kg
- Width
308 mm
- Height
44 mm
- Depth
130 mm
- Cable length
0 mm
- No. of USB type A 3.1 / 3.2 1st Gen
16 x
- Material (details)
Metal
- UKCA
yes
- Operating temperature (T-T)
0 - 55 °C
- Ports quantity
16
- DC-in jack
yes
- USB powered
yes
- Operating relative humidity (H-H)
5 - 95 %
- Storage temperature (T-T)
-20 - 85 °C
Documents & Downloads
Datasheet
Datasheet 3796877 Exsys Exsys EX-1116HMVS - Hub - 16 x USB 3.1 Gen 1 USB hub Black
User & Safety Instructions
User & Safety Instructions 3796877 Exsys Exsys EX-1116HMVS - Hub - 16 x USB 3.1 Gen 1 USB hub Black
Description
The EX-1116HMVS provides 16 screw-able USB 3.0 downstream ports with a protection of the terminals against voltage fluctuations. It is thus possible to connect up to four external USB peripheral devices to a USB 3.0 port of the computer in the 19" rack. The supplied cable EX-K1572V (2 meter) A-plug to B-plug can be attached to the EX-1116HMVS with knurled screws without using a screwdriver. It can be used in automation and office applications. The HUB meets the special requirements of industrial applications. It is very compact and robust.
This text is machine translated.
This text is machine translated.
Features
- Exsys EX-1116HMVS - hub - 16 connections - can be mounted on rack
- Device type: Hub - 16 connections
- Housing Type : Rack mountable
- Sub-type: USB
- Ports : 16 x USB 3.1 1st Gen 1
- Features : 15KV ESD Protector
- Product certificates : USB 2.0, USB 3.0, USB 3.1 Gen 1
- Power supply: DC 12 - 24 V.
- Dimensions (width x depth x height): 30.8 cm x 13 cm x 4.4 cm
- Weighs 1.8 kg
- System requirements : Microsoft Windows CE, Linux, Apple MacOS X 10.x, Microsoft Windows Server 2003, Microsoft Windows Server 2008, Microsoft Windows Vista (32/64 bits), Microsoft Windows 7 (32/64 bits), Microsoft Windows XP (32/64 bits), Windows 8 (32/64 bits), Microsoft Windows Server 2012 R2, Windows 10 (32/64 bits)
Scope of delivery
- EX-1116HMVS, USB 3.0 cable screw able manual, DIN-Rail Kit (EX-6099)
