Exsys EXSYS EX-41388 8S Seriell RS232 PCI Kart PCI card
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
EXSYS EX-41388 interface card / adapter built-in serial
- built-in
- Host Interface: PCI
- Output interface: Serial
Technical specifications
- Product type
PCI card
- Version
Adapter cable
- Type A
PCI
- Depth
61 mm
- Width
120 mm
- Cable use
RS232
- Connection type
PCI
- Transfer type
Corded
- Range of use
PC
- Weight
700 g
- UKCA
not relevant
- Operating temperature (T-T)
0 - 55 °C
- Serial ports quantity
8
- Internal
yes
- Operating relative humidity (H-H)
5 - 95 %
- Storage temperature (T-T)
-40 - 75 °C
- User guide
yes
- Mac compatibility
no
Documents & Downloads
Datasheet
Datasheet 3796879 Exsys EXSYS EX-41388 8S Seriell RS232 PCI Kart PCI card
User & Safety Instructions
User & Safety Instructions 3796879 Exsys EXSYS EX-41388 8S Seriell RS232 PCI Kart PCI card
Description
- Interface: RS-232 V.24
- FIFO buffer: 16C1050 with 256 bytes
- I/O addresses and interrupt: Is assigned by the system BIOS, IRQ sharing
- Data bits: 5, 6, 7, 8 / Stop bits: 1, 1.5, 2 / Parity: None, even, odd, space, mark
- Signals: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
- Supports 5V and 3.3V motherboards.
This text is machine translated.
- FIFO buffer: 16C1050 with 256 bytes
- I/O addresses and interrupt: Is assigned by the system BIOS, IRQ sharing
- Data bits: 5, 6, 7, 8 / Stop bits: 1, 1.5, 2 / Parity: None, even, odd, space, mark
- Signals: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
- Supports 5V and 3.3V motherboards.
This text is machine translated.
Features
- Exsys EX-41388 - Serial adapter - PCI-X - RS-232/V.24 x 8
- Device Type : Serial adapter
- Form factor : Plug-in card - Low profile
- Interface type (bus type) : PCI-X
- Bus-voltage : universal (3.3 V & 5.0 V)
- Ports : RS-232/V.24 x 8
- Dimensions (width x depth x height): 12 cm x 6.1 cm
- Weight: 0.7 kg
- Data Link Protocol : RS-232 V.24
- Data transfer rate : 921.6 Kbps
- System Requirements : SCO Unix, Microsoft Windows XP 64-bit Edition, Microsoft Windows Server 2003, Microsoft Windows 98/ME/2000/XP, Microsoft Windows 7, Microsoft Windows Server 2008 R2, Microsoft Windows 7 64-bit Edition, Linux Kernel 2.4, Microsoft Windows Server 2008, Microsoft Windows Vista (32/64 bits)
Scope of delivery
- EX-41388, Octopus cable, LP bracket, CD, manual
