Faber Kabel 036091 Jumper wire SiD 1 x 1.50 mm² White Sold per metre
EAN:
Part number:
Item no:
Product type
Jumper wire
No. of leads
1 x
Cross section (each core)
1.50 mm²
Cable type
SiD
Outside Ø
2.60 mm
Datasheet (PDF)
Quantity (meter)
Savings
Package size (plus VAT.)
3
-
€ 1.25
10
8% = € 0.10
€ 1.15
25
11% = € 0.14
€ 1.11
Volume discounts vary depending on the seller
You save € 0.00
Total (€ 1.25 / piece)
€ 3.75
plus VAT.
Technical specifications
- Product type
Jumper wire
- No. of leads
1 x
- Content
Sold per metre
- Cross section (each core)
1.50 mm²
- Insulation material
Silicone
- Cable type
SiD
- Outside Ø
2.60 mm
- Nominal voltage
500 V
- Packaged
No
- Halogen-free
No
- Manufacturer part #
036091
- Factory colour
White
- Core layout
Copper; blank; Cl1 = single-wire
- Max. length sold by the metre
100 m
- Sold per metre
Yes
- Nominal voltage U0
300 V
- Cross section
1 x 1.50 mm²
- Max. temperature range (flexible installation)
+180 °C
- Min. temperature range (flexible installation)
-60 °C
- Max. temperature range (fixed installation)
+180 °C
- Min. temperature range (fixed installation)
-60 °C
- Type
SiD
