Fastron 77A-150M-00 77A-150M-00 Choke Axial lead 77A 15 µH 0.06 Ω 4 A 1 pc(s)
EAN:
Part number:
Item no:
Product type
Choke
Type
Axial lead
Inductance (L)
15 µH
Resistance
0.06 Ω
Type
77A
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 2.09
10
8% = € 0.16
€ 1.93
25
11% = € 0.22
€ 1.87
Volume discounts vary depending on the seller
You save € 0.00
Total (€ 2.09 / piece)
€ 2.09
plus VAT.
Technical specifications
- Ferrite core
- Product type
Choke
- Type
Axial lead
- Type
77A
- Inductance (L)
15 µH
- Resonance
100 kHz
- Tolerance ±
10 %
- Resistance
0.06 Ω
- Nominal current
4 A
- Material
Duplex steel
- Length
26 mm
- (Ø)
9 mm
- Content
1 pc(s)
- Dim
(Ø x L) 9 mm x 26 mm
- RoHS-compliant
Yes
- Type
77A-150M-00
- Material (details)
Ferrite
- Type
77A-150
Documents & Downloads
Datasheet
Datasheet 440486 Fastron 77A-150M-00 77A-150M-00 Choke Axial lead 77A 15 µH 0.06 Ω 4 A 1 pc(s)
User & Safety Instructions
User & Safety Instructions 440486 Fastron 77A-150M-00 77A-150M-00 Choke Axial lead 77A 15 µH 0.06 Ω 4 A 1 pc(s)
Description
Multi-layered winding with insulating film.
