FCI SIL socket (standard) No. of rows: 2 Pins per row: 2 89898-302ALF 1 pc(s)
EAN:
Part number:
Item no:
Connector type
Power strip, straight
Product type
SIL socket (standard)
No. of rows
2
Total number of pins
4
CS
2.54 mm
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 0.69
9
9% = € 0.06
€ 0.63
15
12% = € 0.08
€ 0.61
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 0.69 / piece)
€ 0.69
plus VAT.
14-day return policy included
Highlights & Details
Socket terminal strip
- Content 1 pc(s)
- No. of rows 2
- Pins per row 2
Technical specifications
- Connector type
Power strip, straight
- Product type
SIL socket (standard)
- No. of rows
2
- Pins per row
2
- Total number of pins
4
- CS
2.54 mm
- Connection
SMD
- Factory colour
Grey
- Contact surface
Gold plated
- Contact material
Phosphorus bronze
- Case material
Thermoplastic UL94V-O
- Pin Ø
0.60 mm
- Separable
No
- Dim
(L x W x H) 5.08 x 5.08 x 7 mm
- Connector orientation
Perpendicular (to the PCB)
- Manufacturer part #
89898-302ALF
- Socket shape
Square
- Socket depth
2.3 mm
- Industrial packaging
No
- Content
1 pc(s)
- Width
5.08 mm
- Height
7 mm
- Length
5.08 mm
- Max. temperature
+125 °C
- Min. temperature
-65 °C
- Type
Dubox / PV / Bergstik
