Feed-through terminal block UKK 5-MTK-P/P 2800004 Phoenix Contact
EAN:
Part number:
Item no:
Product type
Serial continuity
Connection
Screws
Cross section (flexible) (max.)
4 mm²
Cross section (inflexible) (max.)
4 mm²
Nominal current - rounded value
26 A
Datasheet (PDF)
Number (Package size 50 pc(s))
Total (€ 9.83 / piece)
€ 491.60
plus VAT.
Technical specifications
- Product type
Serial continuity
- Connection
Screws
- Cross section (flexible) (min.)
0.2 mm²
- Cross section (flexible) (max.)
4 mm²
- Cross section (inflexible) (min.)
0.2 mm²
- Cross section (inflexible) (max.)
4 mm²
- AWG (min.)
24
- AWG max.
12
- Clamp width
6.1 mm
- No. of rows
2
- Number of pins
4
- Factory colour
Grey
- Nominal current
26 A
- Nominal current - rounded value
26 A
- Nominal voltage
400 V
- Stripping length (max.)
8 mm
- Manufacturer part #
2800004
- Content
50 pc(s)
- Industrial packaging
Yes
- Type
UKK 5-MTK-P/P
- Dim
(L x W x H) 80 x 6.1 x 68 mm
- Width
6.1 mm
- Height
68 mm
- Length
80 mm
- Contamination level
3
- Flammability rating
V2
- Insulation material
PA
- Insulation
PA
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 565187 Feed-through terminal block UKK 5-MTK-P/P 2800004 Phoenix Contact
User & Safety Instructions
User & Safety Instructions 565187 Feed-through terminal block UKK 5-MTK-P/P 2800004 Phoenix Contact
Description
Feed-through terminal block, Connection type: Screw connection, Cross section: 0.2 mm² - 4 mm², AWG: 24 - 12, Nominal current: 26 A, Nominal voltage: 400 V, Length: 80 mm, Width: 6 mm, Color: gray, Assembly: NS 35/7,5, NS 35/15, NS 32
