Name: FESTO 1310167 DHRS-40-A-NC Radial gripper Enclosure material: Aluminium wrought alloy 1 pc(s)
Brand: FESTO
SKU: 2204624
Availability: BackOrder

Black and white illustration of an electrical switch with two buttons and four screw holes on the sides.

Image similar

Sales and shipping:

Conrad ElectronicTerms & Conditions

Total (€ 1,205.00 / piece)

€ 1,205.00

incl. VAT

Only available for business customers

14-day return policy included

Report legal concerns

Highlights & Details

Technical specifications

No. of jaws: 2
Size: 40
Fastening method: Optional:
Internal thread and centering sleeve
With through hole and centering sleeve
Operating pressure: 4 ... 8 bar
Operating medium: Compressed air according to ISO 8573-1:2010 [7:4:4]
All mounting positions permitted
Operation: Double-acting
Gripper function: Radial
Gripping force protection: When closing
Note on operating and control medium: Oiled operation possible (required in further operation)
Constructive design: Forced motion sequence
Corrosion resistance class KBK: 1 - low corrosion stress
Mass moment of inertia: 4.24 kgcm2
Max. Working frequency gripper:< = 2 Hz
Max. Replacement accuracy< = 0.2 mm
Max. Force at gripping jaws Fz static: 200 N.
Max. Moment on gripping jaws Mx static: 14 Nm
Max. Moment on gripping jaws My static: 14 Nm
Max. Moment on gripping jaws Mz static: 14 Nm
Max. Opening angle 180 degrees
Min Opening time at 6 bar 151 ms
Min Closing time at 6 bar: 110 ms
Pneumatic connection: g1/8
Position detection: For proximity switches
Product weight: 844 g
Rotation symmetry<: = 0.2 mm
Ambient temperature: 5 ... 60 °C
Material covering cap: PA
Material casing: Aluminum wrought alloy
hard anodized
Material gripping jaws: High-alloy steel
Material note: RoHS compliant
Repeat accuracy of gripper:< = 0.1 mm

Operating medium: Compressed Air

Product type: Radial gripper

Enclosure material: Aluminium wrought alloy

Connection: G 1/8

Max. operating pressure: 8 bar

Operating temperature: 5 °C (min)

Min. operating temperature: 5 °C

Manufacturer part #: 1310167

Operating pressure (min.): 4 bar

Accuracy (+/-): 0.1 mm

Weight: 844 g

Medium: Compressed air

Features: P port connector (G1/8)

Max. ambient temperature: +60 °C

Min. ambient temperature: +5 °C

Operating principle: Double-acting

UKCA: not relevant
