Name: FESTO 1310185 DHWS-40-A-NC Angled gripper Enclosure material: Aluminium wrought alloy 1 pc(s)
Brand: FESTO
SKU: 2204633
Availability: BackOrder

Image similar

Sales and shipping:

Conrad ElectronicTerms & Conditions

Total (€ 839.00 / piece)

€ 839.00

incl. VAT

Only available for business customers

14-day return policy included

Report legal concerns

Highlights & Details

Technical specifications

No. of jaws: 2
Size: 40
Fastening method: Optional:
Internal thread and centering sleeve
With through hole and centering sleeve
Operating pressure: 4 ... 8 bar
Operating medium: Compressed air according to ISO 8573-1:2010 [7:4:4]
All mounting positions permitted
Operation: Double-acting
Gripper function: Angle
Gripping force protection: When closing
Note on operating and control medium: Oiled operation possible (required in further operation)
Constructive structure: Lever
Corrosion resistance class KBK: 1 - low corrosion stress
Mass moment of inertia: 3.87 kgcm2
Max. Working frequency gripper:< = 3 Hz
Max. Replacement accuracy< = 0.2 mm
Max. Force at gripping jaws Fz static: 200 N.
Max. Moment on gripping jaws Mx static: 13 Nm
Max. Moment on gripping jaws My static: 13 Nm
Max. Moment on gripping jaws Mz static: 13 Nm
Max. Aperture angle 40 degrees
Min Opening time at 6 bar: 99 ms
Min Closing time at 6 bar: 69 ms
Pneumatic connection: g1/8
Position detection: For proximity switches
Product weight: 795 g
Rotation symmetry<: = 0.2 mm
Ambient temperature: 5 ... 60 °C
Material covering cap: PA
Material casing: Aluminum wrought alloy
hard anodized
Material gripping jaws: High-alloy steel
Material note: RoHS compliant
Repeat accuracy of gripper:< = 0.04 mm

Operating medium: Compressed Air

Product type: Angled gripper

Enclosure material: Aluminium wrought alloy

Connection: G 1/8

Max. operating pressure: 8 bar

Operating temperature: 5 °C (min)

Min. operating temperature: 5 °C

Manufacturer part #: 1310185

Operating pressure (min.): 4 bar

Weight: 790 g

Medium: Compressed air

Features: P port connector (G1/8)

Max. ambient temperature: +60 °C

Min. ambient temperature: +5 °C

Operating principle: Double-acting

UKCA: not relevant
