FESTO Check-choke valve 151183 GRLZ-M5-B 0.2 up to 10 bar External thread M5 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 26.88
3
4% = € 1.17
€ 25.71
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 26.88 / piece)
€ 26.88
plus VAT.
14-day return policy included
Highlights & Details
Check-choke valve GRLZ-M5-B
Technical specifications
- Ambient temperature: -10 °C to 60 °C, Product Weight: 11g
- Operating medium
According to ISO 8573-1:2010 compressed air [7:4:4]
- Product type
Check-choke valve
- External thread
M5
- Min. display range
0.2 bar
- Display range (max.)
10 bar
- Operating temperature
-10 °C (min)
- Min. operating temperature
-10 °C
- Manufacturer part #
151183
- Material (details)
Seals: NBR.
- Connection
M5
- Max. operating pressure
10 bar
- Operating pressure (min.)
0.2 bar
- Pressure range
0.2 up to 10 bar
- Operating medium
Compressed air
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 1896767 FESTO Check-choke valve 151183 GRLZ-M5-B 0.2 up to 10 bar External thread M5 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1896767 FESTO Check-choke valve 151183 GRLZ-M5-B 0.2 up to 10 bar External thread M5 1 pc(s)
Information
Information 1896767 FESTO Check-choke valve 151183 GRLZ-M5-B 0.2 up to 10 bar External thread M5 1 pc(s)
