FESTO Filler plug 177715 CQC-22H Internal thread CQ - 22 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 4.61 / piece)
€ 4.61
plus VAT.
14-day return policy included
Highlights & Details
Technical specifications
- Product weight: 10g
- Operating medium
Compressed air according to ISO 8573-1:2010 [7:-:-]
- Product type
Filler plug
- Internal thread
CQ - 22
- Manufacturer part #
177715
- Vacuum
-0.95 bar
- Max. operating pressure
7 bar
- Min. operating pressure
-0.95 bar
- Material
POM
- Max. ambient temperature
+70 °C
- Min. ambient temperature
-25 °C
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 2116518 FESTO Filler plug 177715 CQC-22H Internal thread CQ - 22 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2116518 FESTO Filler plug 177715 CQC-22H Internal thread CQ - 22 1 pc(s)
Information
Information 2116518 FESTO Filler plug 177715 CQC-22H Internal thread CQ - 22 1 pc(s)
Description
Blind plugs CQC-22H for closing of plug-in connections. Installation position=any, container size = 1, design = Push-pull principle, Operating pressure complete temperature range = -0,95 - 7 bar, temperature-dependent operating pressure = -0,95 - 15 bar
