FESTO Proximity sensor Inductive SMPO-8E 178563 T groove
EAN:
Part number:
Item no:
Product type
Proximity sensor
Model
Inductive
Type
SMPO-8E
Enclosure material
PA
Aluminium
Steel
Installation type
T groove
Datasheet (PDF)
Number
Total (€ 67.22 / piece)
€ 67.22
plus VAT.
Only 7 Piece(s) available
Highlights & Details
Proximity switch SMPO-8E
Technical specifications
- Product weight: 11g
- Valve function: 3/2
- Mounting type: With Through Hole, with accessories
- Product type
Proximity sensor
- Type
SMPO-8E
- Enclosure material
PA
Aluminium
Steel
- Model
Inductive
- Installation type
T groove
- Min. temperature
-15 °C
- Max. temperature
+60 °C
IP65
- Content
1 pc(s)
- Type
Mounting type: with through-hole; Operating medium: compressed air
- Operating medium
According to ISO 8573-1:2010 compressed air [6:4:4]
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 1946158 FESTO Proximity sensor Inductive SMPO-8E 178563 T groove
User & Safety Instructions
User & Safety Instructions 1946158 FESTO Proximity sensor Inductive SMPO-8E 178563 T groove
Description
Proximity switch SMPO-8E pneumatic, for drives with T-slot, without mounting kit. Design = for T-groove, material note = (* copper and PTFE-free, * RoHS compliant), measuring principle = magnetic, Operating pressure = 2 - 8 bar, according to ISO 8573-1:2010 operating medium = compressed air [6:4:4]
