FESTO Tensioner 13290 EV-15/63-4 Enclosure material: Die cast Stroke length: 4 mm 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 63.86 / piece)
€ 63.86
plus VAT.
Only 2 Piece(s) available
Highlights & Details
Tensioner EV-15/63-4
Technical specifications
- Operating medium
Compressed air according to ISO 8573-1:2010 [7:-:-]
- Product type
Tensioner
- Stroke length
4 mm
- Max. operating pressure
6 bar
- Material (details)
Housing: aluminum pressure die-cast
- Min. device temperature
-20 °C
- Device temperature (max.)
+40 °C
- Manufacturer part #
13290
- Weight
65 g
- Min. operating pressure
2 bar
- Sealant
Polyurethane
- Pneumatics connector
M5
- Enclosure material
Die cast
- Material
Aluminium
- Medium
Compressed air
- Max. ambient temperature
+40 °C
- Min. ambient temperature
-20 °C
- Operating principle
Single-acting
- UKCA
not relevant
