Finder 13.81.8.230.0000 Electronic Shock Button
EAN:
Part number:
Item no:
Product type
Impulse changeover switch
Operating voltage
230 V AC
Contact type
1 maker
Mounting type
DIN rail
Type
13.81.8.230.0000
Datasheet (PDF)
120 Piece(s)
Sales and shipping:
Number
Total (€ 57.13 / piece)
€
Highlights & Details
Finder 13.81.8.230.0000 Electronic Shock Button
Technical specifications
- Incandescent lamps: 3000 W, Fluorescent offset: 1000 W, uncompensated fluorescent: 1000 W halogen lamps: 3000 W
- Product type
Impulse changeover switch
- Type
13.81.8.230.0000
- Operating voltage
230 V AC
- Switch-on current
120 A
- Contact type
1 maker
- Contact material
AgSnO2
- Max. switching capacity
3700 VA
- Mounting type
DIN rail
- Min. temperature
-10 °C
- Max. temperature
+60 °C
- Width
17.5 mm
- Height
60.8 mm
- Depth
88.8 mm
- Dim
(W x H x D) 17.5 x 60.8 x 88.8 mm
- Content
1 pc(s)
- RoHS-compliant
Yes
- Nominal voltage (details)
230 V AC
- Switching capacity
(AC1) 3700 VA/(AC15) 750 VA
- Switching current
16 A
- Type
13.81.8.230.0000
- Ambient temperature
-10 - +60 °C
- Operating voltage
230 V AC
- Weight
0.10
DIN rail
Electronic switch
60.8 mm
1
AC
0
1
0
Documents & Downloads
Datasheet
Datasheet 503128 Finder 13.81.8.230.0000 Electronic Shock Button
User & Safety Instructions
User & Safety Instructions 503128 Finder 13.81.8.230.0000 Electronic Shock Button
Description
Electronic shock switch for DIN rail mounting. If, after turning off the control voltage to the starting position Longer service life and low noise as a mechanical shock switch.
Features
- Control input for 100% duty cycle.
Hints
Approvals CE, GOST, IMQ
