Image similar
Image similar
Finder 22.34.0.024.4620 Remote switch 2 breakers, 2 makers 250 V AC, 440 V AC + LED Compatible with (relay brand): Finde
EAN:
Part number:
Item no:
Product type
Remote switch
No. of pins
4-pin
Nominal voltage
250 V AC
440 V AC
Packaging type
Piece
Type
22.34.0.024.4620
Datasheet (PDF)
Number
Total (€ 48.73 / piece)
€ 48.73
plus VAT.
14-day return policy included
Technical specifications
- Installation depth: 60.8 mm
- Number of division units: 2
- Max. Bulb load 2000 W
- Max. Fluorescent lamp load 800 VA
- Max. Fluorescent lamp load (Duo-circuit): 800 VA
- Max. Fluorescent lamp load (parallel compensated): 500 VA
- Additional equipment possible: Yes
- Packaging type
Piece
- Product type
Remote switch
- Type
22.34.0.024.4620
- No. of pins
4-pin
- Contact type
2 breakers
2 makers
- Contact material
AgSnO
- Auxiliary contact type
2 breakers
- Nominal voltage
250 V AC
440 V AC
- Control voltage (min.)
24 V AC
- Control voltage (max.)
24 V AC
- Control voltage range
24 - 24 V AC
- Switching voltage (min.)
250 V AC
- Switching voltage (max.)
24 V DC/AC
- Max. switching capacity
6250 VA
- Permanent current (max.)
25 A
- Compatible with
Finder
- Compatible with series
Finder 22.34 series
- Features
+ LED
- Mounting type
DIN rail
IP20
- Width
35 mm
- Depth
60.8 mm
- Dim
(W x D) 35 mm x 60.8 mm
- Content
1 pc(s)
- RoHS-compliant
Yes
- Weight
900 g
35
88.8 mm
60.8 mm
TRUE
4 kW
2
2
0
0
10 A
25 A
24-24 V
24-24 V
24-24 V
Screw connection
19.2-26.4 V
19.2-26.4 V
AC/DC
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2474502 Finder 22.34.0.024.4620 Remote switch 2 breakers, 2 makers 250 V AC, 440 V AC + LED Compatible with (relay brand): Finde
User & Safety Instructions
User & Safety Instructions 2474502 Finder 22.34.0.024.4620 Remote switch 2 breakers, 2 makers 250 V AC, 440 V AC + LED Compatible with (relay brand): Finde
Description
Installation contactor for 35 mm rail, 2 NO contacts and 2 NC contacts for 25 A / 250 V AC, contact material AgSnO², max. switching power at 230 V AC: AC1 6250 VA, AC15 1800 VA, 3-phase motor load, AC3 (400-440 V AC) 4 kW, rated current AC AC-7c 10 A, incandescent and halogen lamps 2000 W, Compact fluorescent lamp (energy saving lamp) 200 W, fluorescent lamp with EVG 800 W, fluorescent lamp with KVG 500 W, LED (230 V AC) 200 W, NV halogen lamps or LED with EVG 200 W, NV halogen lamps or LED with KVG 800 W. Coil: 24 V AC/DC, width 35 mm, with LED and mechanical switching position display, relay protection type: IP 20
