Finder 34.51.7.012.0019 PCB relay 12 V DC 6 A 1 change-over 20 pc(s)
Item no:
Product type
PCB relay
Coil nominal voltage
12 V DC
Contact type
1 change-over
Switching current (max.)
6 A
Type
34.51.7.012.0019
Total (€ 5.25 / piece)
€ 105.03
plus VAT.
Highlights & Details
- Narrow PCB relay
- 1 changer for 6 A/250 V AC
- Contact material AgNi
- Coil data 12 V DC
- 0.170 W .
- 840 ohms
- Relay protection type RT II.
- Horizontal design with angled pins.
- This text is machine translated.
Technical specifications
- With removable terminals: No.
- Drive, polarity: Non-polarized
- Switching behavior of the drive: Monostable
- With forced contacts: No.
- Type of switch contact: Single contact
- Complete unit with base: No.
- Product type
PCB relay
- Type
34.51.7.012.0019
- Coil nominal voltage
12 V DC
- Contact type
1 change-over
- Switching current (max.)
6 A
IP20
- Width
15 mm
- Height
5 mm
- Depth
28 mm
- Dim
(W x H x D) 15 x 5 x 28 mm
- Content
20 pc(s)
- RoHS-compliant
Yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2473842 Finder 34.51.7.012.0019 PCB relay 12 V DC 6 A 1 change-over 20 pc(s)
