Finder 34.51.7.024.0000 Plug-in relay 24 V AC 6 A 1 change-over 1 pc(s)
EAN:
Part number:
Item no:
Product type
Plug-in relay
Coil nominal voltage
24 V AC
Control mode
monostable, 1 coil
Contact type
1 change-over
Switching voltage (max.)
400 V AC
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 5.03
5
6% = € 0.32
€ 4.71
10
9% = € 0.46
€ 4.57
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 5.03 / piece)
€ 5.03
plus VAT.
14-day return policy included
Technical specifications
- 1-pin changer or 1-pin normally open contact
- Sensitive DC coil, 170 mW
- Control with AC/DC voltage via sockets of the series 93 is possible
- UL approval for the combination of socket and relay on some versions
- Cadmium-free contact material
- 6 kV (1.2/50 μs) between coil/contact
- Product type
Plug-in relay
- Type
34.51.7.024.0000
- Coil nominal voltage
24 V AC
- Control mode
monostable, 1 coil
- Contact type
1 change-over
- Contact material
AgSnO2
- Switching voltage (max.)
400 V AC
- Switching current (max.)
6 A
- Max. switching capacity
1500 VA
- Creepage distance (coil/clips)
8 mm
RT III
- Min. temperature
-40 °C
- Max. temperature
85 °C
- Factory colour
Black
- Length
28 mm
- Width
5 mm
- Depth
15 mm
- Dim
(L x W) 28 mm x 5 mm
- Content
1 pc(s)
- RoHS-compliant
Yes
Documents & Downloads
Datasheet
Datasheet 3393419 Finder 34.51.7.024.0000 Plug-in relay 24 V AC 6 A 1 change-over 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3393419 Finder 34.51.7.024.0000 Plug-in relay 24 V AC 6 A 1 change-over 1 pc(s)
Description
Narrow PCB relay 1 CO contact for 6 A/250 V AC, contact material AgSnO2, coil data 24 V DC, 0.170 W, 3350 Ohm, relay protection RT III sealed
