Finder 39.11.8.230.0060 Crossbar switch 230 V AC 6 A 1 change-over 1 pc(s)
EAN:
Part number:
Item no:
Product type
Crossbar switch
Contact type
1 change-over
Nominal voltage
230 V AC
Switching current (max.)
6 A
Type
39.11.8.230.0060
Technical specifications
- Product type
Crossbar switch
- Type
39.11.8.230.0060
- Connection
Screw terminal
- Max. pick-up voltage
230 V AC
- Contact type
1 change-over
- Contact material
AgNi
- Nominal voltage
230 V AC
- Switching current (max.)
6 A
IP20
- Depth
90.7 mm
- Width
6.2 mm
- Height
87 mm
- Dim
(W x H x D) 6.2 x 87 x 90.7 mm
- Content
1 pc(s)
- RoHS-compliant
Yes
- Control mode
monostable, 1 coil
6 A
6.2 mm
87 mm
90.7 mm
FALSE
Polarity free
Mono stable
FALSE
Single contact
TRUE
Screw connection
230-230 V
230-230 V
Untreated
IP20
TRUE
Other
AC
0
0
1
Thermoplastic
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3219382 Finder 39.11.8.230.0060 Crossbar switch 230 V AC 6 A 1 change-over 1 pc(s)
Description
MasterBASIC narrow coupling relay for DIN rail, with screw connections, modular structure, 1 changer for 6 A contact material AgNi, universal as interface relay in the input to SPS or in the output of SPS can be used to control actuators, LED display, terminals A1 or A2 and 11 can be bridged, coil voltage 230 V AC
