Finder 39.31.7.220.0060 Crossbar switch 220 V DC 6 A 1 change-over Piece 1 pc(s)
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Crossbar switch
Contact type
1 change-over
Nominal voltage
220 V DC
Switching current (max.)
6 A
Technical specifications
- Packaging type
Piece
- Product type
Crossbar switch
- Type
39.31.7.220.0060
- Connection
Screw terminal
- Max. pick-up voltage
220 V DC
- Contact type
1 change-over
- Contact material
AgNi
- Nominal voltage
220 V DC
- Switching current (max.)
6 A
IP20
- Depth
90.7 mm
- Width
6.2 mm
- Height
94.3 mm
- Dim
(W x H x D) 6.2 x 94.3 x 90.7 mm
- Content
1 pc(s)
- RoHS-compliant
Yes
- Control mode
monostable, 1 coil
6 A
6.2 mm
94.3 mm
90.7 mm
FALSE
Polarized
Mono stable
FALSE
Single contact
TRUE
Screw connection
220-220 V
Untreated
IP20
TRUE
Other
DC
0
0
1
Thermoplastic
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3219375 Finder 39.31.7.220.0060 Crossbar switch 220 V DC 6 A 1 change-over Piece 1 pc(s)
Description
MasterPLUS narrow coupling relay for DIN rail, with screw connections, modular structure, 1 changer for 6 A contact material AgNi, universally can be used as coupling relays in the input to SPS or in the output of SPS for controlling actuators, LED display, terminals A1 or A2 and 11 are bridgeable, Output fuse module type 093.63 for 5 x 20 mm fine-wire fuses can be used instead of the dummy plug, coil voltage 220 V DC
