Finder 39.80.0.012.9024 SSR 12 V DC/AC 6 A 1 maker 1 pc(s)
EAN:
Part number:
Item no:
Product type
SSR
Contact type
1 maker
Nominal voltage
12 V DC/AC
Switching voltage (max.)
24 V DC/AC
Switching current (max.)
6 A
Technical specifications
- Product type
SSR
- Type
39.80.0.012.9024
- Connection
Screw terminal
- Contact type
1 maker
- Nominal voltage
12 V DC/AC
- Switching voltage (max.)
24 V DC/AC
- Switching current (max.)
6 A
- Depth
90.7 mm
- Width
6.2 mm
- Height
94.3 mm
- Dim
(W x H x D) 6.2 x 94.3 x 90.7 mm
- Content
1 pc(s)
- RoHS-compliant
Yes
6 A
6.2 mm
94.3 mm
90.7 mm
FALSE
TRUE
FALSE
FALSE
FALSE
TRUE
FALSE
FALSE
TRUE
TRUE
TRUE
FALSE
0.1-21600 s
TRUE
TRUE
TRUE
Screw connection
12-12 V
12-12 V
12-12 V
0
0
0
0
1
0
FALSE
FALSE
TRUE
AC/DC
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3219381 Finder 39.80.0.012.9024 SSR 12 V DC/AC 6 A 1 maker 1 pc(s)
Description
MasterTIMER narrow timer relay for DIN-rail, with screw connections, modular design, SSR contacts 1 NO for 6 A 24 V DC, 8 timer functions: Response delay, switch wiper, impulse generator 0.5 sec., Symmetrical flasher-flasher, pulse on Off-delay via start contact, on-off-delay via start contact, switch wiper via start contact, trailing edge via open start contact, 4 time ranges up to 6 h, LED display, terminals A1 or A2 and 15+ are bridged, output fuse module type 12 for 5 x 20 mm fine-wire fuses can be used instead of the blind plug, coil voltage 093.63 V AC/DC
