Finder 45.71.7.024.1310 PCB relay 24 V DC 16 A 1 maker 1 pc(s)
EAN:
Part number:
Item no:
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 4.61
5
7% = € 0.30
€ 4.31
10
9% = € 0.42
€ 4.19
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 4.61 / piece)
€
Only 9 Piece(s) available
Technical specifications
- With removable terminals: No.
- Drive, polarity: Non-polar
- Switching characteristics of drive: Mono-stable
- With positively driven contacts: No.
- Type of switch contact: Single contact
- Complete unit with socket: No.
- Type
45.71.7.024.1310
- Coil nominal voltage
24 V DC
- Contact type
1 maker
- Switching current (max.)
16 A
- Connection
Print
IP40
- Width
12.5 mm
- Height
28.5 mm
- Depth
40.7 mm
- Dim
(W x H x D) 12.5 x 28.5 x 40.7 mm
- Content
1 pc(s)
- RoHS-compliant
Yes
- Product type
PCB relay
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3323070 Finder 45.71.7.024.1310 PCB relay 24 V DC 16 A 1 maker 1 pc(s)
Description
Power/PCB relay with Faston 250, 1 closer for 16 A / 250 V AC, contact material AgNi, coil data 24 V DC, 0.36 W, 1600 Ohm, relay protection type RT II, high-temperature version 125°C
This text is machine translated.
This text is machine translated.
