Finder 45.71.7.048.1310 PCB relay 48 V DC 16 A 1 maker 1 pc(s)
EAN:
Part number:
Item no:
Product type
PCB relay
Coil nominal voltage
48 V DC
Contact type
1 maker
Switching voltage (max.)
400 V AC
Switching current (max.)
16 A
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 5.03
5
6% = € 0.32
€ 4.71
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 5.03 / piece)
€ 5.03
plus VAT.
14-day return policy included
Technical specifications
- Product type
PCB relay
- Type
45.71.7.048.1310
- Coil nominal voltage
48 V DC
- Min. pick-up voltage
33.6 V DC
- Max. pick-up voltage
57.6 V DC
- Resistance (coil)
6400 Ω
- Contact type
1 maker
- Contact material
AgNi
- Switching voltage (max.)
400 V AC
- Switching current (max.)
16 A
- Max. switching capacity
4000 VA
Relay protection type RT II
- Min. temperature
-40 °C
- Max. temperature
+125 °C
- Length
40.70 mm
- Width
12.50 mm
- Height
28.50 mm
- Dim
(L x W x H) 40.70 x 12.50 x 28.50 mm
- Content
1 pc(s)
- RoHS-compliant
Yes
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3024118 Finder 45.71.7.048.1310 PCB relay 48 V DC 16 A 1 maker 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3024118 Finder 45.71.7.048.1310 PCB relay 48 V DC 16 A 1 maker 1 pc(s)
