Finder 48.P8.7.024.0050 Crossbar switch 24 V DC 10 A 2 change-overs Piece 1 pc(s)
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Crossbar switch
Contact type
2 change-overs
Nominal voltage
24 V DC
Switching voltage (max.)
250 V AC
Technical specifications
- Packaging type
Piece
- Product type
Crossbar switch
- Type
48.P8.7.024.0050
- Connection
Push-in connector
- Contact type
2 change-overs
- Contact material
AgNi
- Nominal voltage
24 V DC
- Switching voltage (max.)
250 V AC
- Switching current (max.)
10 A
- Features
+ LED
IP20
- Depth
75 mm
- Width
15.8 mm
- Height
95.5 mm
- Dim
(W x H x D) 15.8 x 95.5 x 75 mm
- Content
1 pc(s)
- RoHS-compliant
Yes
- Control mode
monostable, 1 coil
10 A
15.8 mm
95.5 mm
75 mm
FALSE
Polarized
Mono stable
FALSE
Single contact
TRUE
Plug-in connection
24-24 V
Untreated
IP20
TRUE
Other
DC
0
0
2
Thermoplastic
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3219360 Finder 48.P8.7.024.0050 Crossbar switch 24 V DC 10 A 2 change-overs Piece 1 pc(s)
Description
Interface relay for DIN rail with push-in connections, 2 CO contact for 10 A / 250 V AC, insulation voltage between adjacent contacts 2,500 V, coil voltage 24 V DC, contact material AgNi, with integrated LED and EMC interference suppression.
