Finder 78.12.1.230.1200 Rail mounted PSU (DIN) 12 V DC 1.25 A 12 W Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 42.01 / piece)
€ 50.41
-17 %
€ 42.01
plus VAT.
Only 10 Piece(s) available
Highlights & Details
Switch cabinet switched-mode power supply 12V/12W
- High efficiency
- Extensive protective circuit
Technical specifications
- Nominal input voltage
110 - 240 V/AC
- Type
Switched PSU
- Product type
Rail mounted PSU (DIN)
- Min. input voltage
100 V AC
140 V DC
- Input voltage (max.)
265 V AC
370 V DC
- Max. output current
1.25 A
- Output current (max.) - rounded
1.25 A
12 W
- Output type (power supply units)
Fixed voltage
- Output voltage (nominal)
12 V DC
- Connection
Screw terminal
- Dim
(L x W x H) 60.8 x 17.5 x 88.8 mm
- Weight
74.00
- Manufacturer part #
78.12.1.230.1200
- Content
1 pc(s)
- Width
17.5 mm
- Height
88.8 mm
- Length
60.8 mm
IP20
- Max. temperature
+60 °C
- Min. temperature
-20 °C
- Type
78.12.1.230.1200
17.5
88.8 mm
56.5 mm
88.8 mm
32 W
17.5 mm
TRUE
1
AC/DC
Screw connection
TRUE
IP20
None
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 2377835 Finder 78.12.1.230.1200 Rail mounted PSU (DIN) 12 V DC 1.25 A 12 W Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2377835 Finder 78.12.1.230.1200 Rail mounted PSU (DIN) 12 V DC 1.25 A 12 W Content 1 pc(s)
Description
This highly efficient switching power supply for input voltages of 110-240 V AC or 220 V DC switches in AC mode at voltage zero crossing, output 12 W at 12 V DC, output nominal current 1 A, internal thermal protection, short-circuit protection at the output, width 17.5 mm, For 35 mm rail (EN 60715)
