Finder 78.36.1.230.2402 SMPSU 24 V 1.7 A 36 W No. of outputs:1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 52.09 / piece)
€ 52.09
plus VAT.
Only 1 Piece(s) available
Highlights & Details
Switched PSU 24 V/36 W
- DIN rail switched-mode power supply
- Input 110-240 V AC or 220 V DC
- Suitable for battery charging applications and for SELV applications (EN 60950)
- At AC voltage the power supply switches at zero crossing
- Output 36 W at 24 V DC
- Output nominal current 1.5 A
- Output voltage range adjustable from 24-28 V DC
- Internal thermal protection
- Short-circuit protection at output
- Width 70 mm
- For mounting rail 35 mm (EN 60715)
- This text is machine translated.
Technical specifications
- Type
One-phase DC industrial switching power supply for control cabinets.
- Nominal input voltage
110 - 240 V/AC
- Product type
SMPSU
- Inputs
1
- Input voltage
100-260 V/AC or 140-370 V DC
- Input voltage (max.)
260 V AC
370 V DC
- Max. output current
1.7 A
- Output current (max.) - rounded
1.7 A
36 W
- Output type (power supply units)
Adjustable
- Output voltage (nominal)
24 V
- No. of outputs
1 x
- Connection
Screw terminal
- Dim
(L x W x H) 61 x 70 x 88.8 mm
- Output voltage (max.)
28 V DC
- Output voltage (min.)
24 V DC
- Operating temperature (max.)
70 °C
- Manufacturer part #
78.36.1.230.2402
- Content
1 pc(s)
- PSU features
Regulated
- Width
70 mm
- Height
88.8 mm
- Length
61 mm
IP20
- Max. temperature
70 °C
- Min. temperature
-20 °C
- Type
78.36.1.230.2402
- Efficiency
90 %
- UKCA
not relevant
