Finder 78.Y1.1.230.2412 SMPSU 20 A 480 W No. of outputs:1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 109.24 / piece)
€ 109.24
plus VAT.
Only 2 Piece(s) available
Highlights & Details
SWITCHED-MODE POWER SUPPLY 20A 24VDC 480W
- Single phase DC industrial switch P/s
- Input 100-240 V AC or 140-338 V DC
- Output 480 W at 24 V DC
- Output voltage adjustable from 24-28 V DC
- Output nominal current 20 A
- Maximum peak current 26 A-5 ms
- Current boost 26 A-3 S
- Internal thermal protection
- Short circuit protection: Hiccup mode
- 2-stage power supply with active PFC
- Width 85.5 mm
- For mounting rail 35 mm (EN 60715)
- This text is machine translated.
Technical specifications
- Type
Single phase DC industrial switching power supply in compact size.
- Product type
SMPSU
- Min. input voltage
90 V AC
127 V DC
- Inputs
1
- Input voltage
100-240 V/AC or 140-338 V DC
- Input voltage (max.)
264 V AC
370 V DC
- Max. output current
20 A
- Output current (max.) - rounded
20 A
480 W
- No. of outputs
1 x
- Dim
(L x W x H) 134.3 x 85.5 x 126.5 mm
- Output voltage (max.)
28 V DC
- Output voltage (min.)
24 V DC
- Manufacturer part #
78.Y1.1.230.2412
- Content
1 pc(s)
- Width
85.5 mm
- Height
126.5 mm
- Length
134.3 mm
IP20
- Max. temperature
70 °C
- Min. temperature
-20 °C
- Type
78.Y1.1.230.2412
- Efficiency
92 %
- UKCA
yes
