Finder 7S.23.9.012.0210 Crossbar switch Nominal voltage: 250 V Switching current (max.): 10 A 2 makers, 1 breaker Piece
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Crossbar switch
Contact type
2 makers
1 breaker
Nominal voltage
250 V
Switching voltage (max.)
12 V DC
Datasheet (PDF)
Number
Total (€ 48.73 / piece)
€ 48.73
plus VAT.
Only 2 Piece(s) available
Technical specifications
- Packaging type
Piece
- Product type
Crossbar switch
- Type
7S.23.9.012.0210
- Connection
Screw terminal
- Response time
7 ms
- Fall time
11 ms
- Contact type
2 makers
1 breaker
- Contact material
AgNi + hard gold plating
- Nominal voltage
250 V
- Switching voltage (max.)
12 V DC
- Switching current (max.)
10 A
- Features
+ LED
IP20
- Max. temperature
70 °C
- Min. temperature
-40 °C
- Width
17.5 mm
- Content
1 pc(s)
- Industrial packaging
Yes
- RoHS-compliant
Yes
