Finder 8A.88.9.024.160C OPTA Digitales SSR Erweiterungsmodul IO module
EAN:
Part number:
Item no:
Product type
IO module
Type
OPTA Digitales SSR Erweiterungsmodul
Operating voltage
12 V DC
24 V DC
Height
88.8 mm
Length
75.5 mm
Datasheet (PDF)
Number
Total (€ 142.85 / piece)
€ 142.85
plus VAT.
Only 5 Piece(s) available
Technical specifications
- Product type
IO module
- Type
OPTA Digitales SSR Erweiterungsmodul
- Operating voltage
12 V DC
24 V DC
- Height
88.8 mm
- Length
75.5 mm
- Width
70 mm
- Dim
(L x W x H) 75.5 x 70 x 88.8 mm
- Manufacturer part #
8A.88.9.024.160C
- Depth
56.5 mm
- Industrial packaging
Yes
IP20
- Connection
Clamp
- Switching current (max.)
3 A
- Switching voltage (max.)
33 V DC
- Min. operating voltage
10.6 V DC
- Max. switching capacity
36 W
- Max. operating voltage
27.5 V DC
- Max. temperature
50 °C
- Min. temperature
-20 °C
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 3588300 Finder 8A.88.9.024.160C OPTA Digitales SSR Erweiterungsmodul IO module
User & Safety Instructions
User & Safety Instructions 3588300 Finder 8A.88.9.024.160C OPTA Digitales SSR Erweiterungsmodul IO module
