Finder SSR 348170059024-20 6 A Switching voltage (max.): 33 V DC 1 pc(s)
EAN:
Part number:
Item no:
Packaging type
Single
Product type
SSR
Control voltage (min.)
3.5 V DC
Control voltage (max.)
12 V DC
Switching voltage (max.)
33 V DC
Highlights & Details
Relay with plug and print connections, input 5 V DC, output SSR 1 closer 6 A/24 V DC
Our service for you
Technical specifications
- Packaging type
Single
- Product type
SSR
- Type
34.81.7.005.9024
- Connection
Jack connector
- Control voltage (min.)
3.5 V DC
- Control voltage (max.)
12 V DC
- Control voltage range
3.5 - 12 V DC
- Control current (max.)
7 mA
- Switching voltage (min.)
1.5 V DC
- Switching voltage (max.)
33 V DC
- Current load (max.)
6 A
- Output voltage (min.)
1.5 V DC
- Output voltage (max.)
33 V DC
- Max. output current
6 A
- RoHS-compliant
Yes
- Permanent current (max.)
6 A
- Content
1 pc(s)
- Nominal control voltage
5 V DC
6 A
DC
Electronic
3.5-12 V
1.5-33 V
FALSE
DC
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3219432 Finder SSR 348170059024-20 6 A Switching voltage (max.): 33 V DC 1 pc(s)
Description
Narrow PCB relay, electronic, input voltage 5 VDC, input current 7 mA, output voltage 1,5-33 VDC, max. Continuous output current 6 A Relay protection type RT III.
