Finder SSR 348170247048-20 0.1 A Switching voltage (max.): 53 V DC 1 pc(s)
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
SSR
Control voltage (min.)
16 V DC
Control voltage (max.)
30 V DC
Switching voltage (max.)
53 V DC
Highlights & Details
Relay with plug and print connections, input 24 V DC, output SSR 1 closer 0.1 A/48 V DC
Our service for you
Technical specifications
- Packaging type
Piece
- Product type
SSR
- Type
34.81.7.024.7048
- Connection
Jack connector
- Control voltage (min.)
16 V DC
- Control voltage (max.)
30 V DC
- Control voltage range
16 - 30 V DC
- Control current (max.)
7 mA
- Switching voltage (min.)
1.5 V DC
- Switching voltage (max.)
53 V DC
- Current load (max.)
0.1 A
- Output voltage (min.)
1.5 V DC
- Output voltage (max.)
53 V DC
- Max. output current
0.1 A
- RoHS-compliant
Yes
- Permanent current (max.)
0.1 A
- Content
1 pc(s)
- Nominal control voltage
24 V DC
0.1 A
DC
Electronic
16-30 V
1.5-53 V
FALSE
DC
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3219414 Finder SSR 348170247048-20 0.1 A Switching voltage (max.): 53 V DC 1 pc(s)
Description
Narrow PCB relay, electronic input voltage 24 VDC, input current 7 mA, output voltage 1,5-53 VDC max. Continuous output current 0.1 A, relay protection RT III.
