Finder SSR 77.31.9.024.8070-5 30 A Switching voltage (max.): 480 V AC Zero crossing 1 pc(s)
EAN:
Part number:
Item no:
Packaging type
Tray
Product type
SSR
Control voltage (max.)
24 V DC
Switching voltage (max.)
480 V AC
Current load (max.)
30 A
Highlights & Details
Electronic relay (SSR), series 77
Technical specifications
- Switch-on current (10 ms) 520 A
- Packaging type
Tray
- Product type
SSR
- Type
773190248070
- Switching type
Zero crossing
- Control voltage (max.)
24 V DC
- Control voltage range
24 V DC (max)
- Surge current (max.)
520 A
- Switching voltage (min.)
48 V AC
- Switching voltage (max.)
480 V AC
- Current load (max.)
30 A
- Max. switching capacity
6000 W
- Output voltage (max.)
480 V AC
- Max. output current
30 A
- Contact type
1 maker
- Min. temperature
-20 °C
- Max. temperature
+80 °C
IP20
- Width
22.5 mm
- Height
83.3 mm
- Depth
120.3 mm
- Content
1 pc(s)
- Nominal current (details)
5 A
- Switching voltage
48 - 265 V AC
- Dielectric strength
5 kV
- Ambient temperature
-20 - +70 °C
22.5
MOSFET
104.5 mm
120.3 mm
1
TRUE
FALSE
FALSE
Screw connection
24-24 V
DC
IP20
TRUE
4-32 V
DC
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3219282 Finder SSR 77.31.9.024.8070-5 30 A Switching voltage (max.): 480 V AC Zero crossing 1 pc(s)
Description
Modular, for 35 mm DIN rails. AC output circuit (anti parallel thyristors), high number of switching cycles (no burning of contact material), noiseless switching and low control capacity.
Design zero-voltage switching: Reduced switch-on current by switching in zero point - particularly suitable for lamp loads (especially energy-saving bulbs) for switching group of lamps and inductive loads and capacities.
Design instant switching: wear-free switching at high switching frequency and higher loads - particularly suitable for resistance loads and inductive loads.
This text is machine translated.
Design zero-voltage switching: Reduced switch-on current by switching in zero point - particularly suitable for lamp loads (especially energy-saving bulbs) for switching group of lamps and inductive loads and capacities.
Design instant switching: wear-free switching at high switching frequency and higher loads - particularly suitable for resistance loads and inductive loads.
This text is machine translated.
Hints
Approvals: CE.
