Fischer 000645 Ankerhülse FIS H 30x1000 L Anchor plug 4 pc(s)
EAN:
Part number:
Item no:
Highlights & Details
Anchor sleeve FIS H 30x1000 L
- Flexible adjustment of lengthThis reduces costs and complexityAnchor plug enables optimum fit in perforated brickGrid structure of the anchor sleeve reduces mortar consumption
Technical specifications
- Suitable for (details): Perforated brick, hollow block made of lightweight concrete, hollow block made of concrete, limestone perforated brick, limestone solid brick, Solid brick, limestone perforated tile, hollow-box ceilings and other perforated stones, solid pumice and other solid building materials
- 30 mm drill nominal diameter
- Dowel length 1000 mm
- Capacity per 10 cm: 26
- Thread dimensions M20
- Application conditions: External/internal area, mainly quiet loads
- Suitable for Ø16/M16 - Ø22/M22
- Product type
Anchor plug
- Material
Steel
- Suitable for
Cored bricks
Hollow block
Flintlime hollow bricks
Flintlime bricks
Solid brick
Hollow pumice slabs
Hollow ceiling panels
Pumice
- Content
4 pc(s)
- Material properties
tempered
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2148014 Fischer 000645 Ankerhülse FIS H 30x1000 L Anchor plug 4 pc(s)
Description
The economical mounting system with injection-armature sleeve as the meter. The fischer metal injection sleeve Meterware is the economic system component for the use of the fisher injection mortar in the brickwork of a hollow stone. The anchor sleeve is cut to length, inserted into the drilled hole, and filled with injection mortar from the bottom of the anchor sleeve. When the anchor rod is set, the mortar is pressed through the grid structure and connects to the perforated stone in the form closure. This will route the load into the building material.The armature sleeve is initially cut to the required length.The anchor sleeve is inserted into the drilled hole and filled with injection mortar by the anchor sleeve base HER.When the fixing element is set, the mortar is pressed through the grid structure of the anchor sleeve and fits optimally to the anchor base. The load is carried off via molded closure.
This text is machine translated.
This text is machine translated.
Features
- The metal filter sleeve can be cut to the required length. It thus enables variable useful lengths with only one product and thus offers flexibility and economic efficiency.The mesh structure of the sieve sleeve ensures uniform mortar distribution in the hole and thus a secure hold.
