Fischer 520359 Plug with internal thread 77.5 mm 12 mm 25 pc(s)
EAN:
Part number:
Item no:
Technical specifications
- Thread: M8
- Min. Screw-in depth: 13 mm
- Max. Screw-in depth: 25 mm
- Min. Drill hole depth with pre-mounted installation: 85 mm
- (Ø)
12 mm
- Product type
Plug with internal thread
- Material
Steel
- Length
77.5 mm
- Screw diameter
8 mm
- Dim
(Ø x H) 12 mm x 77.5 mm
- Content
25 pc(s)
- Outside Ø
12 mm
- Inside diameter
8 mm
- Material properties
zinc galvanized
- Height
77.5 mm
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1879248 Fischer 520359 Plug with internal thread 77.5 mm 12 mm 25 pc(s)
Description
The fischer high-performance anchor FH II-I is an internal thread from galvanically zinc-plated steel. The anchor is in the pre-on mounting. When mounting with an Allen key, the cone in the split sleeve pulled and tightens them against the drill hole wall. At the same time, the anchor through the compression of the black plastic ring. So that is the anchor sleeve approval compliant under the drill hole edge. The fischer high-performance anchor FH II-I is ideal for mounting the air conditioners, sprinkler systems and pipe lines.
