Fischer 520361 Plug with internal thread 77.5 mm 12 mm 25 pc(s)
EAN:
Part number:
Item no:
Highlights & Details
Internal thread FH II 12/M8I A4
Technical specifications
- Thread: M8
- Min. Screw-in depth: 13 mm
- Max. Screw-in depth: 25 mm
- Min. Drill hole depth with pre-mounted installation: 85 mm
- (Ø)
12 mm
- Product type
Plug with internal thread
- Material
Steel
- Length
77.5 mm
- Dim
(Ø x H) 12 mm x 77.5 mm
- Content
25 pc(s)
- Outside Ø
12 mm
- Inside diameter
8 mm
- Material properties
rust-proof
- Height
77.5 mm
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1879036 Fischer 520361 Plug with internal thread 77.5 mm 12 mm 25 pc(s)
Description
The fischer high-performance anchor FH II-I is an internal thread made from stainless steel. The anchor is in the pre-on mounting. When mounting with an Allen key, the cone in the split sleeve pulled and tightens them against the drill hole wall. At the same time, the anchor through the compression of the black plastic ring. So that is the anchor sleeve approval compliant under the drill hole edge. The fischer high-performance anchor FH II-I is ideal for the attachment of Stadium seats, railings and stairs on the outside.
