Fischer 561788 PowerFast II Countersunk wood screw 6 mm 180 mm Spline drive Steel zinc galvanized 100 pc(s)
EAN:
Part number:
Item no:
Highlights & Details
Fischer SilverFast FPF II STP 6.0 x 180 BC 100 step head with internal star TX partial thread galvanized, blue passivated
- The screw geometry of the PowerFast II provides for a fast, comfortable and flexible mounting.
- The chipboard screw has a much smaller crack behavior compared to standard screws.
- The galvanic zinc, blue passivated, does not contain any chromium VI components and is therefore very environmentally friendly.
Technical specifications
- Drive: TX30
- Thread length: 70 mm
- Product type
Countersunk wood screw
- Drive
Spline drive
- Material
Steel
- (Ø)
6 mm
- Length
180 mm
- Head shape
Countersunk
- Dim
(Ø x L) 6 mm x 180 mm
- Content
100 pc(s)
- Material properties
zinc galvanized
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2760610 Fischer 561788 PowerFast II Countersunk wood screw 6 mm 180 mm Spline drive Steel zinc galvanized 100 pc(s)
Description
The Fischer Powerfast FPF II STP BC is a galvanized blue passivated screw with partial thread and internal star mounting. Like the normal countersunk head the step counter head can be simply sunk and in addition has the advantage of higher draft values by the large head diameter. The design with partial thread makes it possible to securely tighten wooden elements.
This text is machine translated.
This text is machine translated.
Features
- Like the normal countersunk head the step counter head can be simply sunk and in addition has the advantage of higher draft values by the large head diameter.
- The increased thread pitch of the screw reduces the screw-in time considerably.
- The screw tip with the three ribs ensures quick bite action and pre milling.
- The shaft milling ribs in combination with the core milling cutter geometry noticeably reduce the screw-in resistance.
- The PowerFast II is a screw with tested loads in the fischer plug (e.g. DuoPower or UX).
