Fischer 573383 FSU-P M16x190/60 Concrete anchor 295 mm 30 mm 4 pc(s)
EAN:
Part number:
Item no:
Highlights & Details
Fischer FSU-P M16x190/60 rear cut anchor
- Highest load and safety level thanks to perfect form closure
- Six cutting teeth generate an overcut independently and quickly
- Low axle and edge distances owing to low spreading forces
- Plastic element fixes the anchor in the drill hole
- DMC for unique identification and reading of product data
- The ETA confirms the useful life of anchorages up to 100 years
Technical specifications
- 30 mm drill nominal diameter
- Drilling hole diameter in the attachment part: 15 - 60 mm
- Max. Thickness of attachment 60 mm
- Thread: M16
- Wrench size: 24 mm
- (Ø)
30 mm
- Product type
Concrete anchor
- Material
Steel
- Length
295 mm
- Dim
(Ø x L) 30 mm x 295 mm
- Suitable for
Concrete
- Content
4 pc(s)
- Material properties
zinc galvanized
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3835331 Fischer 573383 FSU-P M16x190/60 Concrete anchor 295 mm 30 mm 4 pc(s)
Conformity certificate
Conformity certificate 3835331 Fischer 573383 FSU-P M16x190/60 Concrete anchor 295 mm 30 mm 4 pc(s)
Description
The FSU-P Fischer backcut anchor is a self-cutting, electroplated steel tailoring anchor for applications requiring the highest loads and safety (e.g. heavy steel plant construction, nuclear power plants, oil & gas industry). The rear section anchor is suitable Ideal for heavy duty fixing in order to anchor steel structures, heavy pipe work and industrial machines in cracked and untorn concrete indoors. The FSU-P is placed in a hole created with the FSU-ST collar drill in the through-hole mounting using the FSU-ST setting tool. The armature cuts itself the undercut and thereby creates a positive connection. This ensures maximum safety even with large crack widths in seismic areas. The FSU-DT removal tool can be used to remove the armature quickly and without residue.
This text is machine translated.
This text is machine translated.
Scope of delivery
- Fischer FSU-P M16x190/60 rear cut anchor
