Highlights & Details

Fischer DUOTEC 12 S PH with panhead screw

Combination of two material components for more power
Federal sleeve strengthens the drill hole and enables significantly higher transverse loads
Curved handle allows before mounting the feel of obstacles

Technical specifications

Drill nominal diameter 12 mm
Min. Thickness of 12 mm
Max. plate thickness: 55 mm
Min. Cavity depth 50 mm
Screw diameter M 6 mm
Screw length 55 mm
Dowel length 60 mm.

Product type: Cavity plug

Suitable for: Concrete
Plasterboard
Plasterboard
Timber boards
PVC sheets
Chipboard

Content: 10 pc(s)

UKCA: yes

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 1933064 Fischer 542797 DUOTEC 12 S PH M Cavity plug 10 pc(s)

Description

The unique function mode and the dowels geometry of the fischer DUOTEC allow for very high load input. Toggle bolt This reduces the number of attachments in case of multiple attachments and maximize safety. The fischer DUOTEC is a member of the duo-Line of two plastic components. The red and hard component of the anchor sleeve enables the uniform load distribution, the gray and soft prevent damage to the disk surface in the case of attachment and thus a load reduction. For applications in building materials, behind which a hollow space, the fischer DUOTEC as a toggle bolt. In solid substrates can also be used as a wedge anchor of the dowel.
