Fischer Elektronik 10026762
EAN:
Part number:
Item no:
Connector type
Power strip, straight
Product type
SIL socket (precision)
No. of rows
2
Total number of pins
72
CS
2.54 mm
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 23.52
30
4% = € 1.02
€ 22.50
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Multiple: 10
Total (€ 23.52 / piece)
€ 235.20
plus VAT.
14-day return policy included
Highlights & Details
Fischer Elektronik 10026762
- Content 1 pc(s)
- No. of rows 2
- Pins per row 36
Our service for you
Technical specifications
- Connector type
Power strip, straight
- Product type
SIL socket (precision)
- No. of rows
2
- Pins per row
36
- Total number of pins
72
- CS
2.54 mm
- Connection
Print
- Factory colour
Black
- Nominal voltage
150 V DC
- Nominal current
3 A
- Nominal current - rounded value
3 A
- Contact surface
Tin plated
- Contact material
Copper alloy
- Case material
PA 4.6, GF
- Pin length (PCB)
3.10 mm
- Separable
No
- Dim
(L x W x H) 91.44 x 10.1 x 5.08 mm
- Connector orientation
Perpendicular (to the PCB)
- Manufacturer part #
10026762
- Industrial packaging
No
- Content
1 pc(s)
- Width
10.1 mm
- Height
5.08 mm
- Length
91.44 mm
- RoHS-compliant
Yes
- Max. temperature
+163 °C
- Min. temperature
-40 °C
- Type
BL 6 72 Z
Documents & Downloads
Datasheet
Datasheet 737284 Fischer Elektronik 10026762
User & Safety Instructions
User & Safety Instructions 737284 Fischer Elektronik 10026762
Description
Precision socket, protected internal contact, detachable. Plug-enabled for 0.55 mm to 0.65 mm and 0.65 mm to Ø 0.85 mm. Tin plated contact sleeve.
