FTCAP Electrolytic capacitor Radial lead 18 mm 10.000 µF 100 V 20 % (Ø x H) 40 mm x 70.0 mm 1 pc(s) Single
Part number:
Item no:
Packaging type
Single
Product type
Electrolytic capacitor
Type
Radial lead
Capacity (elec.)
10.000 µF
Nominal voltage
100 V
Datasheet (PDF)
Highlights & Details
FTCAP EL cap 10000UF 100V 40x70mm
Our service for you
Technical specifications
- ESD Packaging: No ESD
- Series GM
- Design_1: Radial
- Mounting type_1: Screw terminals and bolt mounting
- Delivery form_1: Loose
- Connections_1: 2-pin
- Mounting bolt thread M8x12
- Pitch_1:18 mm
- Climate category IEC 40/85/56
- Capacity 10,000 µF
- Capacity_1: 10,000
- Unit of capacity: µF
- Capacity Tolerance 20%
- Loss factor tan δ: 0.1
- Equivalent Series Resistance (ESR): 16 mOhm
- Nominal voltage DC 100 V
- Lifetime_1: 8,000 h
- Packaging type
Single
- Product type
Electrolytic capacitor
- Type
Radial lead
- CS
18 mm
- Dim
(Ø x H) 40 mm x 70.0 mm
- Capacity (elec.)
10.000 µF
- Nominal voltage
100 V
- Tolerance ±
20 %
- Height
70.0 mm
- (Ø)
40 mm
- Content
1 pc(s)
- Width
40 mm
- Length
70.0 mm
- RoHS-compliant
Yes
- Max. temperature
85 °C
- Min. temperature
-40 °C
- Type
GMB10310040070
- Operating temperature (max.)
85 °C
- Operating temperature (min.)
-40 °C
- Certification marks
IEC 60384-4
Documents & Downloads
Datasheet
Datasheet 3462896 FTCAP Electrolytic capacitor Radial lead 18 mm 10.000 µF 100 V 20 % (Ø x H) 40 mm x 70.0 mm 1 pc(s) Single
User & Safety Instructions
User & Safety Instructions 3462896 FTCAP Electrolytic capacitor Radial lead 18 mm 10.000 µF 100 V 20 % (Ø x H) 40 mm x 70.0 mm 1 pc(s) Single
Description
F&T Elko series: GMB
